Garbage Chutes
Garbage Chutes
Why Horizon Garbage Chutes?
Uncompromised Fire Safety
UL-labeled fire-rated doors (90 minutes, UL10B Standard), automatic fire cut-off discharge doors, and self-closing hopper doors tested for up to 120 mins fire rated coppers also available as option.
Hygiene First
Sustainability & Compliance
Our Products
Standard Garbage Chutes
Key Features
- Available in SS316, SS304, SS430, and Galvanised Iron with auto-closing, fire-rated doors, UL 10B labelled doors for optimal safety.
- Engineered-angle adjustable cleaning sprinklers at every intake level for optimal sanitation.
- Internal chute sanitation is controlled via a panel in the garbage room.
- Integrated cleaning system ensures hygienic waste management throughout.
- Intake doors are auto-closing and fire-rated for maximum safety.
- Available in different diameters & Hopper sizes
Available Sizes
MOC : SS316, SS304, SS430 & 41.
Diameter: 450(mm), 500(mm), 600(mm),750(mm), 900(mm)
Hopper sizes: 12”*15”, 16”*18”, 21”*21”, 24”*24”
Thicknesses: 1.2mm, 1.5mm, 2mm, 3mm
Additional size available on request.
ADA (Americans with Disabilities Act) compliant and pneumatically operated hoppers.
Top-Tier Compliance
- 90-minute fire-rated UL-labeled 10B doors
- UL-10 Listed chute system controller
- UL 508A-certified control panel
- NFPA 82. NBC 2005
Segregated Garbage Chutes
Horizon’s Bisorter, Trisorter, and Quadrasorter systems are designed to meet municipal trash segregation standards, automating waste collection sorting into wet, dry, and recyclable fractions.
Keypad-Based System
- Push-button selection: Dry/Wet/Other waste types
- Automated flap diverter mechanism / sorter in chute chamber
- One-user-at-a-time interlock logic; all other hoppers locked during operation
- Auto-closing hopper with 10s reset time
- Hopper and controller UL-rated
- Reduces infrastructure by eliminating multiple chute lines
- Max capacity: 15 floors / 80 apartments per chute.
Available configurations
- Bisorter – 2 waste types
- Trisorter – 3 waste types
- Quadrasorter – 4 waste fractions.
Top Tier Industry Compliance
- 90 min fire-rated UL Labelled 10B chute-type doors
- UL - 10 Controller for chute systems
- UL 508A complaints Control Panel
Interlocking Garbage Chutes
Key Features
- One User at a Time" technology prevents simultaneous usage.
- As additial safety features Intake hoppers automatically lock during operation and cleaning.
- Fire-rated, self-closing hoppers for safety available in UL 10B labelled 90 mins & 120 mins fire rating.
- Improved maintenance safety: hoppers lock during cleaning cycles, while replacing trolles.
- ADA Compliant pneumatically operated
- Intake hoppers available with 3D volume control to reduce the volume of garbage thrown to avoid eventual clogging.
- Available with RFID readers, touch screen controls, etc.
Top Tier Industry Compliance
- UL-labeled 90-minute fire-rated doors
- UL-listed controller & UL 508A-certified control panel
Accessories & Enhancements
At Horizon Chutes, we know that waste management goes beyond disposal. Our Accessories & Enhancements improve hygiene, safety, and efficiency while meeting strict compliance standards. From odor control, brush cleaning system to compaction, these add-ons make garbage chute systems cleaner, safer, and more reliable.
Why Accessories & Enhancements?
- Odor Control System, herbal mist technology, eliminates foul gases.
- Brush Cleaning System, nylon brushes ensures hygienic chute.
- Rotary Carousels with Compactor, rotating bins with integrated volume reduction, enables reducing in garbage removal.
- Clog Warning System, non-contact sensors with audio-visual clog alerts.
- Sound Deadener, specialized internal coating, reduces noise frequency during disposal.
- Static Compactor, automated compaction, reduces volume of dry weste.
Our Products
Odor Control System
Keeps enclosed waste rooms fresh with herbal liquid misting that neutralizes unpleasant gases.
Brush Cleaning System
Automated nylon brushes with water spray ensure chute interiors remain hygienic with minimal manual intervention.
Rotary Carousels with Vertical Bin Compactor
Rotating bins simplify garbage collection while integrated compactors reduce waste volume efficiently.
Clog Warning System
Non-contact sensors detect obstructions, with audio-visual alerts to identify clog location instantly.
Sound Deadener
A specialized internal coating minimizes the noise of falling waste, creating a quieter environment.
Chute Feed Static Garbage Compactor
Automated compaction upon entry, with alerts at 80% and 100% capacity for timely maintenance.
Top-Tier Compliance
- BS 1703:2005 (British Standards)
- NFPA 82 (National Fire Protection Association)
- NBC 2005 (National Building Code)
- IS 6924:2001 (Indian Standards)
Building for the Best
From global hospitality giants to India’s leading developers, our solutions power the biggest names in the industry.
