High Performance Fire Rated & Blast Resistant Doors 30, 60, 90, 120, 240 (min)
Engineered for Safety, Designed for Performance
As a UL-listed manufacturer (UL 10B) with 25 years of expertise, we deliver solutions tailored to today’s construction demands. Our fire doors are engineered to prevent the spread of fire and smoke, enable safe egress, and ensure compliance with international and local building codes.
Every door is an assembly of three critical components: Frame, Shutter, and Ironmongery (handles, locks, hinges, etc.), engineered to meet performance, aesthetic, and safety benchmarks.
Why Choose Horizon Doors?
- Fire Door tested as per IS 3614, BS 476 Part 20 & 22.
- Certified performance for Insulation, Integrity, and Stability criteria.
- UL 10B-listed products ensure global compliance.
- Hardware selected and tested for fire conditions and day-to-day architectural requirements.
- Add Designed to meet architectural needs instead of day-to-day architectural requirements.
- Custom-built solutions as per occupancy and fire zone classification.
- OEM partnership & authorizsed applicator with Promat International for advanced fire protection materials.
- Available in single or double leaf, with or without vision panels, in a wide range of finishes.
- Professional installation as per the tested fixing methodology.
Our Products
Metal Fire Doors
Metal Fire Doors, also known as HMPS (Hollow Metal Pressed Steel) doors, are engineered to provide critical protection against the spread of fire and smoke. At Horizon, our fire doors are tested and certified to comply with the latest fire safety norms and are trusted for both residential and commercial buildings where passive fire protection is mandatory.
Key Features
- Fire rating: 120 minutes (2 hours) for integrity and stability
- Tested as per IS 3614 and BS 476 Part 20 & 22.
- Supplied as a complete door set with frame, shutter, and fire-rated hardware.
- Available in 30, 60, 90, 120, and 240-minute fire ratings.
- 20 to 120 minute insulation using Rockwool as per NBC 2016.
- Single or double leaf configurations with optional vision panels.
- Finish options include synthetic enamel paint or powder coating.
- Frames available in single rabbet, double rabbet, or with architrave.
- Compatible with panic bars, door closers, locks, handles, and access control systems.
- Non fire rated metal doors are also available
- Planned with various seats for accoustic ratings.
120-Minute Metal Fire Doors
- Tested at CBRI Roorkee.
- Certified for 2-hour integrity and stability and upto 120 minutes insulation.
- Constructed using galvanized steel, mild steel, or stainless steel.
- Frame thickness is 1.2 mm; shutter thickness is 0.8 mm and abovewith 1.2 mm sheet. Frame Thickness available in 1.2 mm and above.
- Proprietary Insulation material for 120 minutes insulation.
- Optional fire-rated hardware includes panic devices, mortise and cylinder locks, hydraulic closers, concealed tower bolts, and vision panels as required.
Sliding Fire Doors
When hinged doors aren’t viable due to wide access needs, like in basements, warehouses, and industrial zones, Sliding Fire Doors provide a heavy-duty, fire-compliant solution. Horizon, in collaboration with Promat International, delivers engineered sliding door sets built to your exact project specifications.
Key Features
- Certified fire rating up to 120 and 240 minutes as per BS 476 Part 20 & 22.
- Used for basement compartmentation when area exceeds 3000 sq.m as per NBC 2016.
- Slides shut automatically during fire via gravity-led counterweights and fusible link.
- Remote closing possible via solenoid connected to main fire panel or BMS. Installed near driveways; stays open under normal conditions and auto-closes in fire.
- Available up to 25m² size for vehicular and equipment clearance.
- Shutter made with Promatech or Durasteel boards, single rabbet 3-side frame with welded joints.
- Heavy-duty MS track with bottom rollers and recessed handles.
- Wicket gate option available for personnel egress.
- Horizontal or vertical slide options with single or double leaf configurations.
- Factory-applied zinc primer, topcoat to be applied at site.
Blast Resistant Doors and Partitions
Engineered to Endure Extreme Conditions
Designed for high-risk environments like chemical plants, power stations, and pharmaceutical units, Horizon’s Blast Resistant Doors are developed in partnership with Promat International. These systems withstand blast pressures, reduce structural damage, and meet the highest safety codes.
Key Features
- Blast-resistant systems designed for petrochemical units, defence zones, gas banks, and hazardous storage areas.
- Doors and partitions built with 75mm Durasteel or Promatech boards with or without core infill.
- Frames fabricated from structural steel for high-impact blast resistance.
- Fire rating up to 240 minutes as tested and certified.
- Custom-built sizes and configurations based on site pressure tables.
- Compatible with both concrete and steel wall openings.
- Available models include Duracheck, Duraflush, and the H60 series.
- Zinc primer finish applied at the factory; site topcoat optional.
- Partitions use steel frames spaced as per blast force dynamics.
- Blast release panels pivot outward to relieve sudden pressure surges.
- Panels auto-reset post-deployment and are ideal for confined control spaces.
Tunnel Doors Supplied for Prestigious Project: Atal Tunnel, Rohtang
Enhancing tunnel safety with passive fire protection systems that safeguard road tunnels against fire hazards, ensuring faster response and greater resilience in emergencies. With over 35 years of expertise, we specialize in cross passage door and partition systems, delivering durable, certified, and fully compliant solutions for critical infrastructure projects.
Key Features
- Technicals such as Standard and 35 years of experience in passive fire protection
- Successfully commissioned for: Atal Tunnel, Pandoh Tunnel, Samruddhi Mahamarg Tunnel
- Systems rigorously tested and certified, fully compliant with tender specifications
- Advanced control systems for people evacuation and vehicle passage doors
- SCADA-controlled operation with local pendant override for flexibility
- Cross-passage doors designed to pressurize passages, isolate fire zones, and prevent flame and toxic gas propagation
Best-In-Class Passive Fire Protection (PFP)
- Specialization in cross passages between tunnel tubes
- In case of fire, traffic is diverted safely, ensuring personnel and vehicles can evacuate
- Fire doors and barriers installed to isolate fire zones
- Doors placed at both ends or middle of cross passages
Our Projects
- Four Laning Of end of Pandoh Bypass to Takoli, Himachal Pradesh
- Samruddhi Mahamarg Pkg-14 Nagpur-Mumbai.
- Reasi site For Konkan Tower 06
- Sangaldan Site For Konkan T40
- Rohtang Pass Highway Tunnel Lot 2
Include codes and standards for Tunnel Doors
“Codes & Standards: The design, manufacture and testing specification shall comply with the latest issue of the following standards:
- BS: 476:PART 22:1987: Codes and standard for Fire test on building & structures
- IS 3614: Part 1: Specification for Fire-check Doors - Part 1
- IS 15 3614: Part 2: Specification for metallic and non-metallic fire check doors - Resistance test and performance criteria
- NFPA 80: Standard for Fire Door and Other Opening Protective
- NFPA 92: Standard for Smoke Control Systems
- NFPA 502: Standard for Road Tunnels, Bridges, and Other Limited Access Highways
Building for the Best
From global hospitality giants to India’s leading developers, our solutions power the biggest names in the industry.
FAQ's
What are Horizon Metal Fire Doors?
Hollow Metal Pressed Steel (HMPS) doors engineered to prevent fire and smoke spread, tested per IS 3614-2021 and BS 476 Part 20 & 22, available in 30–240 min fire ratings with single/double leaf and optional vision panels.
Where are Sliding Fire Doors used?
Ideal for basements, warehouses, industrial zones, or any wide-access areas. Doors auto-close via gravity/fusible link or BMS trigger, supporting up to 25 m² openings with vehicular clearance.
What makes Horizon Blast Resistant Doors unique?
Designed for high-risk environments like chemical plants, refineries, defense, and gas banks. Doors and partitions withstand blast pressures, are fire-rated up to 240 minutes, and use 75mm Durasteel/Promatect boards with structural steel frames.
What are the main components of a Horizon fire door?
Frame, shutter, and ironmongery (locks, handles, hinges, closers), all engineered for fire performance, aesthetic compliance, and operational reliability.
What fire ratings are available for Horizon doors?
Metal Fire Doors: 30, 60, 90, 120, 240 minutes; Blast & Sliding Fire Doors: up to 240 minutes. Fire-rated hardware ensures integrity, stability, and insulation compliance.
Can Horizon Fire Doors be customized?
Yes-single/double leaf, sliding/horizontal/vertical, vision panels, multiple finishes, and bespoke sizes for specific fire or blast requirements.
How are Sliding Fire Doors activated during emergencies?
Automatically via gravity-led counterweights, fusible links, or remotely via solenoid connected to the fire panel/BMS. Wicket gates allow personnel egress.
Are Horizon Blast Resistant Doors compatible with standard structures?
Yes-frames work with concrete or steel walls, and partitions use steel frameworks spaced per blast force calculations. Release panels pivot outward to relieve sudden pressure surges.
What certifications and standards do Horizon Fire Doors comply with?
IS 3614-2021, BS 476 Part 20 & 22, NBC 2016, and UL-listed hardware where applicable. CBRI (Central Building Research Institute) doors are tested at NABL-accredited labs for integrity and stability.
Why choose Horizon Fire Doors?
Tested, certified, and professionally installed solutions that combine fire and blast protection, aesthetic flexibility, and operational reliability for residential, commercial, and industrial applications.
